MK120 IR Beam Break Detector

Code: LL64U


2.4  out of 5 based on 5 reviews
Write a Review

Product details

MK120 IR Beam Break Detector

Create an infra red ‘virtual barrier’ with this interesting minikit. The transmitter emits a beam of infra red light which is picked up by the matching receiver. If the beam is broken (i.e. by someone walking through it) the receiver sounds an alarm and illuminates an LED. Ideal for indoor security or visitor annunciation applications. Specifications: PP3 Battery holder and power socket included.

Reviews

Write a Review

5 of 5 Reviews

  • Ir beam kit

    I got one of these kits and assembled it and the pads came off with very minimal effort. It Ended up in my " I will never use it "cupboard . :(

    Was this review useful?  Yes No  1 1

  • i would definitely agree with the other 1-star reviewer as the instructions where difficult to comprehend meaning i had to take about 5 resistors off one board and when i tried to solder the correct resistors onto the board,about half of the copper pads came off! Maplin is my favourite shop but to be honest,i think i have been let down on this one.

    Was this review useful?  Yes No  7 1

  • I bought this kit, I wish I hadn't! I attempted to assemble it but found the copper track came away from the board as soon as any heat was applied to it. I was unable to assemble the kit for the track falling off the board and leaving components floating and flopping around, the instructions are poor and somewhat misleading. I gave it my best and I've assembled other similar kits with no trouble before; but this kit ended up in the bin, I wouldn't recommend this kit to anyone, poor quality tracking that comes away from the board easily.

    Was this review useful?  Yes No  7 3

  • I found the kit ideal for modification into an infared camera shutter release for wild life photography. The modification was a simple, I just substituted the buzzer in the kit for a maplin relay (code n16aw) and conected a 3.5 jack (so as to plug the shutter cable on my 7d into) to the gate on the pin. now I am taking great pictures as wild life trips the beam.

    Was this review useful?  Yes No  15 0

  • Good quality kit which was a excellent price and works perfectly.

    Was this review useful?  Yes No  9 0

Questions

Ask a Question

10 of 16 Questions

  • keith sutton said:

    could i use this with the correct interface to trigger my camera in high speed photography?

    We can see no reason why not, however we are unable to advise on the modification of our items.

    Was this answer useful?  Yes No  4 1

  • JAMIE L said:

    once activated can you stop the buzzer without turning the unit off ?

    Yes the product does support that.

    Was this answer useful?  Yes No  2 0

  • gary said:

    Can you use this as a counter, for example how many cows walk into a barn?

    No sorry this product does not support that.

    Was this answer useful?  Yes No  1 0

  • simon said:

    would i be able to use this item to detect someone coming in my gate by sounding the alarm indoors.

    Yes the product does support that.

    Was this answer useful?  Yes No  3 0

  • david said:

    Would this be able link to an FM radio transmitter instead of a buzzer for a secuity system?

    No sorry this product does not support that.

    Was this answer useful?  Yes No  1 1

  • Perry king said:

    Does this kit need more than one power source or are the boards linked by a wire or something?

    This requires 2 batteries, one for each unit.

    Was this answer useful?  Yes No  3 0

  • Kararchi said:

    Is there any programming involved with this kit or does the IC come already programmed?

    The Ic is preprogrammed

    Was this answer useful?  Yes No  3 0

  • Greg Evans said:

    could you tell me the maximum distance between transmitter and receiver

    Approx 1.4 meters

    Was this answer useful?  Yes No  1 0

  • Tom said:

    Hi, is it possible to replace the alarm with a LED or a similar form of component?

    Yes with the correct interfacing circuits, unfortunatley we cannot advise more than this.

    Was this answer useful?  Yes No  1 0

  • Claire said:

    hi, will the beam be strong enough to use above a 54w, 1149mm strip light?

    I would say not to be honest.

    Was this answer useful?  Yes No  1 1

Bulk Prices

Item code Item name Quantity Price
LL64U MK120 IR Beam Break Detector (100+) £8.24
LL64U MK120 IR Beam Break Detector (25+) £8.79
LL64U MK120 IR Beam Break Detector (10+) £9.34
LL64U MK120 IR Beam Break Detector (5+) £9.89
LL64U MK120 IR Beam Break Detector (1+) £10.99
