Maplin Plus 12V 10 Amp Smart Battery Charger for Lithium LiFePO4 Batteries

About this product

The Maplin Plus 12V 10 Amp Smart Battery Charger for Lithium LiFePO4 Batteries features cutting-edge charging technology with an intelligent microprocessor-controlled 10A current/voltage (CC/CV) automatic two-step charge process, ensuring both fast and complete charging.

Specifically designed for 4-cell LiFePO4 battery packs with a nominal voltage range of 12.8V to 13.2V, this 12V 10Ah LiFePO4 battery charger is optimised to deliver efficient and reliable charging performance.

Equipped with CPU control and pulse width modulation (PWM) technology, this charger ensures precise control over charging current and output voltage. It employs a constant current (CC) and constant voltage (CV) charging mechanism, guaranteeing safe and effective charging for 24V lithium-ion/LiFePO4 batteries of any capacity.

Charging Current: 10A

Charging Voltage: 14.5V

Floating Voltage: 13.7V

Safety measures include safeguards such as Over Voltage Protection, Short Circuit Protection, and Output Reverse Protection. Additionally, the charger ensures output isolation from input and employs high-frequency switching for over 90% efficiency. It also features an automatic cut-off of charge power upon reaching full battery capacity, enhancing safety and longevity.

LED charge indicator switches from red to green when fully charged and output then cuts.

LED indicators: * LED is Red = Charging * LED is Green = Fully Charged
